Main Features:-Â
- 2.8″ Sharp and Large Display ensures clear view from distance
- Compact aluminum enclosures and robust construction
- Compatible with mostly standard IV Sets
- Users friendly interface for easy operation
- Precise control of the infusion rate and infusion volume
- Different Infusion Modes meet most clinical needs
- Residual infusion time can be displayed during infusing
- Anti-bolus System to improve infusion safety
Special safety measures
- Accompanying lV-set clamp prevents liquid flowing freely when the pump door opens accidentally.
- Air bubble detector with high accuracy prevents air bubbles from entering patient’s body.
- Pressure sensor prevents occlusion for lV set.
- A.B.S system, when the high-voltage occlusion alarm appears, stop infusing immediately, and eliminate the pressure of the lV set automatically, which prevents instantaneous high-dose injection from the sudden obstruction disappearing.
- lnfusion parameters during infusing are protected against being changed arbitrarily.
- With password protection function(in system parameter setting and lV set type interface.
Function:
- Flow control with high accuracy ensures optimum therapeutic effect.
- Be compatible with most standard lV Sets.
- New lV set provided by user can be calibrated by suppliers,and infusion parameters can be input into the pump, which ensures accuracy .
- 2.8″TFT-LCD.
- Operate with keys.
- Residual infusion time can be displayed during infusing.
- With reminder function for starting infusion.
- Alarm for occlusion, air bubble, door open and motor failure, etc.
- Threshold for pressure alarm can be adjusted by medical personnel.
- Accompanying lV-set clamp prevents liquid flowing freely when the pump door opens accidentally.
- A.B.S——ANTIBOLUS system prevents instantaneous high-dose injection from the sudden obstruction disappearing.
- Â Stop infusing automatically during alarm(except for “NEAREND”, “KVo”, and “LOWBATTERY” alarms).
- Power supply: AC/DC and built-in lithium battery.
- lnfusion parameters can be saved after power off.
Technical Specification:
- Type: volumetric infusion pump
- lnfusion rate: 1~699mL/h, increment: 1mL/h
- Total volume: 1~9999mL, increment: 1mL
- Accuracy: ±5%(use the lV set calibrated)
- Display information: flow rate, total volume, accumulated infusion volume, residual time
- Safety classification: class l，type BF applied part
- Â Waterproof degree: IPX2
- Working mode: continuous working
- Alarm functions: near end, KVO state, low battery, no power, pressure failure, door failure, air bubble, door open, occlusion, infusion reminder and motor failure.
- Air bubble detector: ultrasonic
- TFT: 2.8″
- KVO rate: 1mL/h(can not be adjusted)
- Sensitivity for pressure sensor: 1~3 grades(it can be adjusted by professional medical personnel)
- Power supply: AC:100~240V,50/60Hz Rechargeable Li-polymer battery,7.4V/5000mAh
- Dimension: 143.6.mm(L)×151.8mm(W)×195.3 mm(H)
- Weight: 1.9kg
